7.2V AA Ni-MH Rechargeable Battery Pack 2000mAh with White Connector

Q: What is cycle‑life of this 7.2V AA 2000mAh Ni‑MH pack?

≥500 cycles tested following IEC61951‑2:2017 standard under 0.2C charge‑discharge test conditions for assembled battery pack.

Q: What is total internal resistance for 7.2V AA2000mAh battery pack?

≤210mΩ for whole assembled pack, measured at 1KHz AC under fully‑charged status.

Q: Can you customize wires, connectors and heat‑shrink housing for this 7.2V AA pack?

Yes. We support custom lead wires, JST/SM/KET/Tamiya connectors, heat‑shrink tube wrapping and polarity adjustment for OEM projects.

Q: What certificates can you provide for export of 7.2V AA Ni‑MH battery packs?

PPWR, CE, RoHS, REACH, MSDS and UN38.3 shipping documents can be supplied for global export orders.

Q: Are samples available for 7.2V AA 2000mAh Ni‑MH battery pack?

Samples can be arranged for performance validation, buyer shall cover the freight cost.

WEIJIANG original 7.2V AA Ni-MH rechargeable battery pack, rated capacity 2000mAh, assembled with 6 pieces of grade-A 1.2V AA cells in series via precision spot welding, equipped with standard white connector for direct plug-and-play installation.

Featuring low total internal resistance (≤210mΩ), flat discharge platform and ≥450 IEC standard cycles for assembled pack, it delivers reliable and consistent power for medium-power devices. Widely applied in security surveillance systems, portable medical equipment, small power tools, RC models and industrial standby power modules.

All battery packs undergo strict capacity & internal resistance matching before assembly, and 100% performance inspection before delivery. We support full OEM customization including lead wire length, connector type, heat-shrink wrapping and polarity adjustment, with complete international safety certifications for global export.

Get a Quote Download

Description

Full Technical Specifications (WJ‑PACK‑6S‑AA2000)

Parameter Item	Specification
Model Number	WJ‑PACK‑6S‑AA2000
Nominal Voltage	7.2V (6pcs 1.2V AA Ni‑MH cells in series)
Rated Capacity	2000mAh (Minimum 1940mAh)
Nominal Energy	14.4Wh
Cell Configuration	6S‑1P (Six standard AA Ni‑MH 2000mAh cells series‑welded)
Single Cell Dimension (D×H)	Φ14.5mm × 50.5mm
Pack Approx Weight	Approx 172g (without connector)
Whole‑Pack Internal Resistance (1kHz, full charged)	≤210 mΩ
IEC Cycle Life	≥500 cycles (IEC61951‑2:2017)
Max Continuous Discharge Current	4000mA (2C)
Standard Charge	200mA (0.1C), 16 hours
Fast Charge	600mA‑1000mA with ‑ΔV / temperature cut‑off control
Discharge Temperature Range	-10℃ ~ +50℃
Short‑term Storage Temperature (<30 days)	-20℃ ~ +45℃
Pack Cut‑off Discharge Voltage	6.0V (1.0V per single cell)
28‑day Self‑discharge Retention	≥65% capacity @20℃ ambient
Certifications & Shipping Documents	PPWR, CE, RoHS, REACH, MSDS, UN38.3 available

Core Performance Advantages

≥500 IEC standard cycles: Assembled from grade‑A WJ‑H‑AA2000 cells, pass IEC61951‑2‑2017 cycle test for RC hobby and portable industrial equipment.
6S series 7.2V finished AA battery pack: Factory spot‑welded six AA‑2000mAh cells, stable 7.2V rated output for RC models and replacement‑device projects.
Strict cell matching process: Capacity, internal‑resistance and open‑circuit voltage sorted before spot‑welding, minimize voltage drift under heavy‑load continuous discharge.
High‑rate discharge capability: Support up to 2C continuous discharge, excellent pulse‑current performance for RC car, power‑tool‑type loads.
Wide working temperature: Discharge range from‑10℃ up to +50℃, fit indoor equipment and mild outdoor operating scenarios.
Flexible OEM options: Custom flying leads, Tamiya/JST/SM/KET connectors, heat‑shrink sleeve wrapping, polarity adjustment and private label printing.

Performance Characteristic Curves

1.0C Rate Charging Curves

0.1C‑1.0C Multi‑Rate Charging Curves

0.2C / 0.5C / 2C Discharging Curves

Storage & Self‑Discharge Retention Curves

OEM Custom Battery‑Pack Service

We provide OEM & ODM finished‑pack assembly service for WJ‑PACK‑6S‑AA2000 7.2V Ni‑MH battery. We support grade‑A cell sorting, spot‑weld inter‑cell tabs, different gauge flying leads, multiple industry‑standard connectors (Tamiya, JST‑PH, SM, KET), heat‑shrink tube insulation, custom polarity and private label printing. Suitable for RC‑model replacement, portable instrument upgrade and new‑product‑development projects.

7.2V AA Ni‑MH battery pack assembly and QC workflow

Typical Application Scenarios

This 7.2V AA 2000mAh series Ni‑MH battery pack is widely applied for RC hobby models, portable test instruments, garden equipment, handheld power tools and portable standby power units.

RC car & hobby model power packs Portable test measuring instruments Hand‑held small power tools Garden robotic equipment Portable emergency lighting Portable industrial control modules

Frequently Asked Questions

Q1: What is cycle‑life of this 7.2V AA 2000mAh Ni‑MH pack?

A: ≥500 cycles tested following IEC61951‑2:2017 standard under 0.2C charge‑discharge test conditions for assembled battery pack.

Q2: What is total internal resistance for 7.2V AA2000mAh battery pack?

A: ≤210mΩ for whole assembled pack, measured at 1KHz AC under fully‑charged status.

Q3: Can you customize wires, connectors and heat‑shrink housing for this 7.2V AA pack?

A: Yes. We support custom lead wires, JST/SM/KET/Tamiya connectors, heat‑shrink tube wrapping and polarity adjustment for OEM projects.

Q4: What certificates can you provide for export of 7.2V AA Ni‑MH battery packs?

A: PPWR, CE, RoHS, REACH, MSDS and UN38.3 shipping documents can be supplied for global export orders.

Q5: Are samples available for 7.2V AA 2000mAh Ni‑MH battery pack?

A: Samples can be arranged for performance validation, buyer shall cover the freight cost.

Manufacturer & Certification Support

Weijiang Power manufactures this 7.2V AA Ni‑MH assembled battery pack with grade‑A original WJ‑H‑AA2000 Ni‑MH cells. In‑house cell‑sorting, spot‑welding and reliability‑testing laboratory support mass‑production and small‑batch OEM customization. Full set export‑ready certification & shipping documents for worldwide customers.

View All Certifications > Factory & Testing Lab Showcase >
