Designing the rechargeable backup for a mains-powered or wireless-interconnected smoke alarm means engineering for a paradox: the cell must be instantly ready after years of doing nothing, yet deliver a loud, radio-active alarm the instant mains disappears. That paradox resolves into a clear set of design tasks - sizing stored energy to a defined evacuation and operating window after mains loss, managing years of float or trickle readiness without degrading the cells, delivering the piezo horn and RF interconnect pulse from a low-impedance source, implementing the low-battery monitoring EN 14604 requires, and building in the reliability a life-safety device demands. This second paper works through those tasks for low-self-discharge nickel-metal hydride: choosing cell format and capacity for the backup window, designing the charge-management that holds the pack ready for a decade, exploiting low internal resistance for the acoustic and radio pulse, setting robust end-of-life detection, and validating the backup against the repeated outage and alarm events of a long service life.
Unlike a ten-year standalone, a mains-backup is sized to a bounded mission: when mains fails, the alarm must remain capable of monitoring, of sounding the 85-decibel horn for the required duration and - in interconnected units - of keeping the radio mesh alive for a defined evacuation and emergency-services window. The designer sums the quiescent monitoring current, the horn duty and the radio traffic across that window, adds margin for low-battery-warning operation and for capacity loss with age, and arrives at a modest, precisely targeted capacity.
Because the mission is bounded, a small NiMH pack - one or two AAA or AA cells, or a compact custom pack - is often sufficient, which keeps the alarm's size and cost in line with a ceiling-mounted product. The sizing always uses worst-case current: horn active, radio transmitting and end-of-life capacity simultaneously, so the device meets its evacuation window at the moment of minimum capability rather than only when new and idle.
The defining engineering challenge is holding a NiMH pack at readiness for the alarm's roughly ten-year design life without overcharge damage. The charge-management circuit applies a carefully limited maintenance current or a temperature-compensated float regime sized to compensate self-discharge rather than to force full charge continuously, and it cycles the pack opportunistically so cells are not held at an extreme state of charge. Low-self-discharge cell grades are essential because their small maintenance-current need makes benign float design straightforward.
Good practice periodically exercises the pack - a controlled partial discharge and recharge - to keep the chemistry healthy and to measure its actual capacity, which doubles as a self-test of backup health. The charger monitors cell temperature and suspends maintenance charge outside the safe range. Done correctly, this lets the NiMH backup match the alarm's service life with no user intervention, while always returning to full readiness after each real mains event - the core advantage over a consumable primary backup.
The piezo horn draws current in acoustic pulses and the interconnect radio adds transmit bursts, and both must be supplied without dragging the controller below its brown-out threshold. NiMH's low internal resistance - tens of milliohms in a charged cell - is the enabling property, holding a flat voltage through the horn's pulse train where a higher-impedance source would sag and possibly reset the controller mid-alarm.
A small local reservoir capacitor complements the cell, supplying the sharpest piezo and RF transients while the NiMH cell replenishes it between pulses, and the power layout separates the high-current horn loop from the sensitive optical-sensor and controller supply to keep detection stable during the alarm. Designing for the simultaneous worst case - horn sounding, radio broadcasting, aged cell - is what guarantees the alarm does not self-silence at the critical moment.
EN 14604 requires a timely low-power warning while the alarm can still sound, and the backup design must detect approaching end of capability reliably. NiMH helps here with a flat 1.2-volt plateau across most of its capacity followed by a defined end drop; the monitoring firmware learns the discharge behaviour, distinguishes a transient horn load from genuine depletion, and triggers the standard chirp while reserving enough energy for the mandated warning period and a final full alarm.
In a rechargeable backup the logic also distinguishes a one-off deep mains outage from genuine end-of-life: after mains restores and recharges the pack, a capacity-check determines whether the low warning was situational or permanent, avoiding nuisance chirps that cause users to disable alarms - a documented real-world failure mode. This smarter monitoring is easier to implement against NiMH's repeatable, cycle-stable discharge curve than against the drifting curve of an ageing primary.
Cell selection favours low-self-discharge grades with proven cycle life and consistent low internal resistance, procured as matched lots so multi-cell packs behave uniformly. Welded tabs and positive retention survive years on a ceiling subject to vibration and temperature swings; the pack is isolated from heat sources and positioned for the alarm's ambient range, and a thermal sensor supports charge management. Conformal protection guards against the humidity of kitchens and bathrooms within the alarm's intended locations.
Where redundancy is warranted - in interconnected or commercial-grade units - the design can parallel cells or add a small reserve so a single weak cell cannot silence the alarm, and the self-test reports pack health to the user or building system. These choices reflect a life-safety philosophy: every element is designed so that the failure of any single consumable does not remove protection, and the rechargeable backup is treated as a permanent, monitored subsystem rather than a disposable part.
Validation replays the backup's whole life in compressed form. Mains-interruption tests confirm the switch to backup is seamless and that monitoring, horn at 85 decibels and interconnect radio all run for the target window at aged capacity; repeated outage cycles confirm the pack returns to full readiness each time; an accelerated float-life test, with temperature used to compress calendar time, checks that capacity and impedance stay within bounds across the equivalent of a decade; and worst-case tests combine horn, radio, cold and end-of-life simultaneously.
Acoustic measurements verify the required sound pressure is maintained on backup power, and radio tests confirm interconnected alarms still propagate the alarm command. A design that passes this programme - and then the EN 14604 conformity and battery-standard evidence in the final paper - delivers a rechargeable backup that is genuinely ready at any moment across the alarm's service life, which is the entire justification for choosing NiMH in a life-safety role.
